CX-444-Z

Active

Panasonic Industrial Automation Sales

SENSOR REFLECTIVE 100MM NPN OPEN

Search across all available documentation for this part.

Active

Panasonic Industrial Automation Sales

SENSOR REFLECTIVE 100MM NPN OPEN

Technical Specifications

Parameters and characteristics for this part

Part	Output Configuration	Light Source	Connection Method	Voltage - Supply [Min]	Voltage - Supply [Max]	Sensing Method	Operating Temperature [Max]	Operating Temperature [Min]	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Max]	Sensing Distance [Min]	Cable Length	Cable Length	Ingress Protection	Response Time
Panasonic Industrial Automation Sales CX-444-P	PNP - Open Collector	Red LED	Cable	12 V	24 V	Reflective	55 °C	-25 °C	0.591 "	100 mm	3.937 "	1.5 cm	78.74 in	2 m	IP67	1 ms
Panasonic Industrial Automation Sales CX-444-P-Z	PNP - Open Collector	Red LED	4POS Connector M8	12 V	24 V	Reflective	55 °C	-25 °C	0.591 "	100 mm	3.937 "	1.5 cm			IP67	1 ms
Panasonic Industrial Automation Sales CX-444-Z	NPN - Open Collector	Red LED	4POS Connector M8	12 V	24 V	Reflective	55 °C	-25 °C	0.591 "	100 mm	3.937 "	1.5 cm			IP67	1 ms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Reflective Optical Sensor 0.591" ~ 3.937" (15mm ~ 100mm) NPN - Open Collector
