BB3803W

Obsolete

TE Connectivity Raychem Cable Protection

RF ANT 450MHZ WHIP STR NMO BASE

Search across all available documentation for this part.

Obsolete

TE Connectivity Raychem Cable Protection

RF ANT 450MHZ WHIP STR NMO BASE

Technical Specifications

Parameters and characteristics for this part

Part	Frequency Range [Max]	Frequency Range [Min]	Frequency (Center/Band)	Termination	VSWR	Power - Max [Max]	Number of Bands	Antenna Type	Gain	Mounting Type	Frequency Group [Max]	Frequency Group [Min]	Height (Max) [Max]	Height (Max) [Max]
TE Connectivity Raychem Cable Protection BB3803WS	520 MHz	380 MHz	450 MHz	NMO	2	200 W	1	Whip Straight	3 dBi	Base Mount	1 GHz	300 MHz	9.921 "	252 mm
TE Connectivity Raychem Cable Protection BB3803WR	520 MHz	380 MHz	450 MHz	NMO	2	200 W	1	Whip Straight	3 dBi	Base Mount	1 GHz	300 MHz	9.125 in	231.78 mm
TE Connectivity Raychem Cable Protection BB3803W	520 MHz	380 MHz	450 MHz	NMO	2	200 W	1	Whip Straight	3 dBi	Base Mount	1 GHz	300 MHz	9.25 in	234.95 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RF ANTENNA Whip, Straight NMO Base Mount
