UTRA4301S3NB-001
ActiveTE Connectivity Raychem Cable Protection
UHF PHANTOM,NMO,B FC 430-490 MHZ,
Deep-Dive with AI
Search across all available documentation for this part.
UTRA4301S3NB-001
ActiveTE Connectivity Raychem Cable Protection
UHF PHANTOM,NMO,B FC 430-490 MHZ,
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | UTRA4301S3NB-001 |
|---|---|
| Antenna Type | Dome |
| Frequency (Center/Band) | 460 MHz |
| Frequency Group [Max] | 1 GHz |
| Frequency Group [Min] | 300 MHz |
| Frequency Range [Max] | 490 MHz |
| Frequency Range [Min] | 430 MHz |
| Gain | 3.6 dBi |
| Height (Max) | 86.6 mm |
| Height (Max) [Max] | 3.409 in |
| Ingress Protection | IP67 |
| Mounting Type | Base Mount |
| Number of Bands | 1 |
| Termination | NMO |
| VSWR | 2.5 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 43.62 | |
| 10 | $ 40.69 | |||
| 30 | $ 38.99 | |||
| 100 | $ 35.33 | |||
| 250 | $ 34.11 | |||
Description
General part information
UTRA4301 Series
Dome/Puck Antenna, Single Band, UHF, External Mount, Stud/Screw/Lug Mount, NMO, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
