T1M-15-F-SV-L

Active

Samtec Inc.

1.00 MM DISCRETE WIRE TERMINAL S

Search across all available documentation for this part.

Active

Samtec Inc.

1.00 MM DISCRETE WIRE TERMINAL S

Technical Specifications

Parameters and characteristics for this part

Specification	T1M-15-F-SV-L

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	3 µin
Contact Finish Thickness - Mating	0.076 µm
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3.3 A
Fastening Type	Locking Ramp
Insulation Color	Natural
Insulation Height [custom]	5.51 mm
Insulation Height [custom]	0.217 in
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	15
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.039 in
Pitch - Mating	1 mm
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	250 VAC, 353 VDC

Part	Mounting Type	Contact Material	Insulation Color	Operating Temperature [Max]	Operating Temperature [Min]	Shrouding	Contact Finish - Post	Insulation Height	Insulation Height	Voltage Rating	Contact Type	Pitch - Mating	Pitch - Mating	Connector Type	Number of Positions	Termination	Material Flammability Rating	Fastening Type	Style	Insulation Material	Contact Shape	Number of Positions Loaded	Number of Rows	Current Rating (Amps)	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height [custom]	Insulation Height [custom]	Contact Finish - Mating
Samtec Inc. T1M-15-T-SH-L	Surface Mount Right Angle	Phosphor Bronze	Natural	85 °C	-55 °C	Shrouded - 4 Wall	Tin	4.6 mm	0.181 in	250 VAC 353 VDC	Male Pin	0.039 in	1 mm	Header	15	Solder	UL94 V-0	Locking Ramp	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	Square	All	1	3.3 A
Samtec Inc. T1M-15-T-S-V-TR	Surface Mount	Phosphor Bronze	Natural	85 °C	-55 °C	Shrouded - 4 Wall	Tin	4.25 mm	0.167 in	250 VAC 353 VDC	Male Pin	0.039 in	1 mm	Header	15	Solder	UL94 V-0	Locking Ramp	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	Square	All	1	3.3 A
Samtec Inc. T1M-15-F-SV-L	Surface Mount	Phosphor Bronze	Natural	85 °C	-55 °C	Shrouded - 4 Wall	Tin			250 VAC 353 VDC	Male Pin	0.039 in	1 mm	Header	15	Solder	UL94 V-0	Locking Ramp	Board to Cable/Wire	Liquid Crystal Polymer (LCP)	Square	All	1	3.3 A	3 µin	0.076 µm	5.51 mm	0.217 in	Gold
