SC2200A-00A00E
ActiveAnalog Devices Inc./Maxim Integrated
IC AMP CDMA 698MHZ-2.7GHZ 80QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SC2200A-00A00E
ActiveAnalog Devices Inc./Maxim Integrated
IC AMP CDMA 698MHZ-2.7GHZ 80QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | SC2200A-00A00E | SC2200 Series |
|---|---|---|
| Current - Supply | 1.3 A | 1.3 A |
| For Use With/Related Products | - | SC2200 |
| Frequency | - | 2.4 - 1900 MHz |
| Frequency [Max] | 2.7 GHz | 2.7 GHz |
| Frequency [Min] | 698 MHz | 698 MHz |
| Gain | 10 dBi | 10 dBi |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 80-VFQFN Exposed Pad | 80-VFQFN Exposed Pad |
| RF Type | W-CDMA, WiMax, CDMA, LTE | W-CDMA, WiMax, CDMA, LTE |
| Supplied Contents | - | Board(s) |
| Supplier Device Package | 80-QFN (11x11) | 80-QFN (11x11) |
| Type | - | PDL (Pre-Distortion Linearizer) |
| Voltage - Supply | 1.8 V | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 500 | $ 107.08 | |
SC2200 Series
EVK, DUAL-RFPAL, 698-960MHZ
| Part | Frequency | Type | Supplied Contents | For Use With/Related Products | Package / Case | RF Type | Frequency [Max] | Frequency [Min] | Mounting Type | Current - Supply | Gain | Supplier Device Package | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated SC2200-EVK900 | 900 MHz | PDL (Pre-Distortion Linearizer) | Board(s) | SC2200 | |||||||||
Analog Devices Inc./Maxim Integrated SC2200-EVK2400 | 2.4 GHz | PDL (Pre-Distortion Linearizer) | Board(s) | SC2200 | |||||||||
Analog Devices Inc./Maxim Integrated SC2200A-00A00 | 80-VFQFN Exposed Pad | CDMA, LTE, W-CDMA, WiMax | 2.7 GHz | 698 MHz | Surface Mount | 1.3 A | 10 dBi | 80-QFN (11x11) | 1.8 V | ||||
Analog Devices Inc./Maxim Integrated SC2200-EVK1900 | 1900 MHz | PDL (Pre-Distortion Linearizer) | Board(s) | SC2200 | |||||||||
Analog Devices Inc./Maxim Integrated SC2200A-00A00E | 80-VFQFN Exposed Pad | CDMA, LTE, W-CDMA, WiMax | 2.7 GHz | 698 MHz | Surface Mount | 1.3 A | 10 dBi | 80-QFN (11x11) | 1.8 V |
Description
General part information
SC2200 Series
RF Amplifier IC CDMA, LTE, W-CDMA, WiMAX 698MHz ~ 2.7GHz 80-QFN (11x11)
