AM15C-2412S-NZ

Obsolete

aimtec

DC DC CONVERTER 12V 15W

Search across all available documentation for this part.

Obsolete

aimtec

DC DC CONVERTER 12V 15W

Technical Specifications

Parameters and characteristics commom to parts in this series

DC DC CONVERTER 12V 15W

Part	Efficiency	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Current - Output (Max) [Max]	Power (Watts)	Voltage - Output 1	Type	Features	Number of Outputs	Voltage - Isolation	Applications	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]
aimtec AM15C-2412S-NZ	90 %	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	1.25 A	15 W	12 V	Isolated Module	Remote On/Off	1	1.5 kV	ITE (Commercial)	18 V	-40 °C	105 ░C	36 V	Through Hole
aimtec AM15C-1212S-NZ	90 %	25.4 mm	9.9 mm			25.4 mm		1.25 A	15 W	12 V	Isolated Module	Remote On/Off	1	1.5 kV	ITE (Commercial)	9 V	-40 °C	105 ░C	18 V	Through Hole	25.4 mm	1 in	0.39 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 19.28

General part information

Isolated Module DC DC Converter 1 Output 12V 1.25A 18V - 36V Input
