PM610-05-RC

Obsolete

Bourns Inc.

INDUCT ARRAY 6 COIL 11.6UH SMD

Deep-Dive with AI

Search across all available documentation for this part.

PM610-05-RC

Obsolete

Bourns Inc.

INDUCT ARRAY 6 COIL 11.6UH SMD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PM610-05-RC

Current Rating - Parallel	4.08 A
Current Rating - Series [custom]	680 mA
Current Saturation - Parallel [custom]	7.8 A
Current Saturation - Series	1.3 A
DC Resistance (DCR) - Parallel	34 mOhm
DC Resistance (DCR) - Series	1.212 Ohm
Height [z]	0.307 in
Height [z]	7.8 mm
Inductance - Connected In Parallel	11.6 µH
Inductance - Connected In Series	417.6 µH
Mounting Type	Surface Mount
Number of Coils	6
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	12-SMD, Gull Wing
Shielding	Unshielded
Size / Dimension [x]	15 mm
Size / Dimension [x]	0.591 in
Size / Dimension [y]	0.63 in
Size / Dimension [y]	16 mm
Tolerance	10 %

PM610 Series

Part	Package / Case	Mounting Type	Tolerance	DC Resistance (DCR) - Series	Current Rating - Series [custom]	Current Saturation - Parallel	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Number of Coils	Current Rating - Parallel	Height [z]	Height [z]	Inductance - Connected In Parallel	Shielding	Inductance - Connected In Series	Current Saturation - Series	DC Resistance (DCR) - Parallel	Current Saturation - Parallel [custom]	Current Saturation - Parallel [diameter]
Bourns Inc. PM610-02	12-SMD Gull Wing	Surface Mount	30 %	564 mOhm	1 A	360 mA	-40 °C	105 ░C	15 mm	0.63 in	16 mm	0.591 in	6	6 A	0.307 in	7.8 mm	78.4 µH	Unshielded	2.82 mH	60 mA	16 mOhm
Bourns Inc. PM610-05	12-SMD Gull Wing	Surface Mount	10 %	1.212 Ohm	680 mA		-40 °C	105 ░C	15 mm	0.63 in	16 mm	0.591 in	6	4.08 A	0.307 in	7.8 mm	11.6 µH	Unshielded	417.6 µH	1.3 A	34 mOhm	7.8 A
Bourns Inc. PM610-05-RC	12-SMD Gull Wing	Surface Mount	10 %	1.212 Ohm	680 mA		-40 °C	105 ░C	15 mm	0.63 in	16 mm	0.591 in	6	4.08 A	0.307 in	7.8 mm	11.6 µH	Unshielded	417.6 µH	1.3 A	34 mOhm	7.8 A
Bourns Inc. PM610-01-RC	12-SMD Gull Wing	Surface Mount	30 %	1.212 Ohm	680 mA		-40 °C	105 ░C	15 mm	0.63 in	16 mm	0.591 in	6	4.08 A	0.307 in	7.8 mm	160 µH	Unshielded	5.76 mH	40 mA	34 mOhm		240 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

PM610 Series

Unshielded 6 Coil Inductor Array 417.6 µH Inductance - Connected in Series 11.6 µH Inductance - Connected in Parallel 34mOhm DC Resistance (DCR) - Parallel 4.08 A 12-SMD, Gull Wing
