MSBP-05BFFA-SL8001
ActiveAmphenol LTW
CONN M12 B FEM 5PIN SCREW THREAD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MSBP-05BFFA-SL8001
ActiveAmphenol LTW
CONN M12 B FEM 5PIN SCREW THREAD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MSBP-05BFFA-SL8001 |
|---|---|
| Cable Opening [diameter] | 4.5 mm, 6.5 mm |
| Cable Opening [diameter] | 0.256 in, 0.177 in |
| Color | Silver |
| Connector Type | Female Sockets, Plug |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 4 A |
| Features | Coupling Nut, Backshell |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Orientation | B |
| Shell Finish | Nickel |
| Shell Material | Zinc Alloy |
| Shell Size - Insert | M12-5 |
| Shielding | Unshielded |
| Voltage Rating | 60 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 9.90 | |
| 10 | $ 8.91 | |||
| 100 | $ 7.96 | |||
| 1000 | $ 5.89 | |||
Description
General part information
MSBP-05BFFA Series
5 Position Circular Connector Plug, Female Sockets Solder Cup
