LP38502 Series

Part	Number of Regulators	Protection Features	Output Configuration	Control Features	Current - Output	Current - Quiescent (Iq)	PSRR (Maximum)	PSRR (Minimum)	Voltage Dropout (Max)	Voltage - Output (Max)	Voltage - Output (Min/Fixed)	Current - Supply (Max)	Output Type	Mounting Type	Package Name	Voltage - Input (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case
Texas Instruments LP38502TJ-ADJ/NOPB	1	Over Current Over Temperature Short Circuit	Positive	Enable	1.5 A	15 µA	58 dB	56 dB	0.37 V	5 V	0.6 V	4 mA	Adjustable	Surface Mount	TO-263-5 Thin	5.5 V	125 °C	-40 °C	TO-263-5 Thin
Texas Instruments LP38502TJ-ADJ/NOPB	1	Over Current Over Temperature Short Circuit	Positive	Enable	1.5 A	15 µA	58 dB	56 dB	0.37 V	5 V	0.6 V	4 mA	Adjustable	Surface Mount	TO-263-5 Thin	5.5 V	125 °C	-40 °C	TO-263-5 Thin
