SM-31W500

Active

Nidec Components Corporation

TRIMMER 50 OHM 0.125W J LEAD TOP

Search across all available documentation for this part.

Active

Nidec Components Corporation

TRIMMER 50 OHM 0.125W J LEAD TOP

Technical Specifications

Parameters and characteristics for this part

Part	Adjustment Type	Resistive Material	Power (Watts)	Power (Watts)	Mounting Type	Resistance	Temperature Coefficient	Number of Turns	Tolerance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Termination Style
Nidec Components Corporation SM-31W502	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	5 kOhms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W504	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount		100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W205	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	2 MOhms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W201	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	200 Ohms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W501	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	500 Ohms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W500	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	50 Ohms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W104	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	100 kOhms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead
Nidec Components Corporation SM-31W203	Top Adjustment	Cermet	0.125 W	0.125 W	Surface Mount	20 kOhms	100 ppm/°C	5	20 %	3.2 mm	0.126 "	0.154 in	3.9 mm	J Lead

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	200	$ 2.95

General part information

50 Ohms 0.125W, 1/8W J Lead Surface Mount Trimmer Potentiometer Cermet 5.0 Turn Top Adjustment
