TSC-105D3H000
ActiveTE Connectivity Raychem Cable Protection
RELAY TELECOM SPDT 1A 5V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TSC-105D3H000
ActiveTE Connectivity Raychem Cable Protection
RELAY TELECOM SPDT 1A 5V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TSC-105D3H000 |
|---|---|
| Coil Current | 60 mA |
| Coil Resistance | 83 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 5 VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 1 A |
| Mounting Type | Through Hole |
| Must Operate Voltage | 3.75 VDC |
| Must Release Voltage | 0.25 VDC |
| Operate Time | 5 ms |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -30 ░C |
| Relay Type | Telecom |
| Release Time | 5 ms |
| Seal Rating | Sealed - Fully |
| Switching Voltage | 30 VDC, 120 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 20 | $ 4.14 | |
Description
General part information
TSC-105 Series
Telecom Relay SPDT (1 Form C) Through Hole
