Specification	BSA906N0087201A000

Connector Type	Plug Housing
Contact Shape	Circular
Fastening Type	Push-Twist
Features	Coupling Nut, Cable Clamp, Backshell
Housing Color	Silver
Includes	Cable Clamp, Backshell, Connector
Includes Total Count	3 pcs
Ingress Protection Description	Dust Tight, Waterproof, Water Resistant
Ingress Protection IP Rating	IP67, IP66
Insert Material	PBT, Polybutylene Terephthalate
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	9
Operating Temperature (Max)	130 °C
Operating Temperature (Min)	-20 °C
Orientation	Keyed
Position Types	PE, Power
Shell Finish	Nickel
Shell Material	Zinc Die Cast
Shielding	Shielded
Type	For Female Sockets

BSA90 Series

Part	Ingress Protection Description	Ingress Protection IP Rating	Material Flammability Rating	Shell Finish	Features	Type	Number of Positions	Position Types	Orientation	Fastening Type	Connector Type	Shell Material	Mounting Type	Shielding	Housing Color	Operating Temperature (Min)	Operating Temperature (Max)	Contact Shape	Insert Material	Note	Includes Total Count	Includes
TE Intercontec BSA906N0087201A000	Dust Tight Water Resistant Waterproof	IP66 IP67	UL94 V-0	Nickel	Backshell Cable Clamp Coupling Nut	For Female Sockets	9	PE Power	Keyed	Push-Twist	Plug Housing	Zinc Die Cast	Free Hanging (In-Line)	Shielded	Silver	-20 °C	130 °C	Circular	PBT Polybutylene Terephthalate	Contacts Not Included	3 pcs	Backshell Cable Clamp Connector
