1800934

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 2 POS 5.08MM PITCH PLUG 24-12 AWG SCREW

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 2 POS 5.08MM PITCH PLUG 24-12 AWG SCREW

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	1800934	MSTBT Series

Color	Black	Green, Black
Contact Mating Finish	Tin	Tin
Current - IEC	12 A	12 A
Features	-	Mating Flange
Housing Material	-	Polyamide (PA), Nylon
Insulation Height	0.591 in	0.591 in
Insulation Height	15 mm	15 mm
Material Flammability Rating	-	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Number of Levels	1	1
Number of Positions	2	2 - 11
Pitch [x]	0.2 in	0.2 in
Pitch [x]	5.08 mm	5.08 mm
Positions Per Level	2	2 - 11
Screw Size	M3	M3
Termination Style	Screw - Rising Cage Clamp	Screw - Rising Cage Clamp
Torque - Screw [Max]	0.6 Nm	0.6 Nm
Torque - Screw [Max]	5.3 Lb-In	5.3 Lb-In
Torque - Screw [Min]	4.4 Lb-In	4.4 Lb-In
Torque - Screw [Min]	0.5 Nm	0.5 Nm
Type	Plug, Female Sockets	Plug, Female Sockets
Voltage - IEC	250 V	250 - 630 V
Voltage - UL	-	300 V
Wire Gauge or Range - AWG [Max]	30 AWG	30 AWG
Wire Gauge or Range - AWG [Min]	12 AWG	12 AWG
Wire Gauge or Range - mm² [Max]	2.5 mm²	2.5 mm²
Wire Gauge or Range - mm² [Min]	0.2 mm²	0.2 mm²
Wire Strip Length	7 mm	7 mm

Pluggable Terminal Blocks 4 Pos 5mm pitch Plug 24-12 AWG Screw

Part	Current - IEC	Positions Per Level	Number of Positions	Material Flammability Rating	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Features	Number of Levels	Screw Size	Housing Material	Contact Mating Finish	Wire Strip Length	Pitch [x]	Pitch [x]	Termination Style	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Voltage - UL	Type	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Mounting Type	Color	Insulation Height	Insulation Height	Voltage - IEC
Phoenix Contact 1805385	12 A	11	11	UL94 V-0	30 AWG	12 AWG	Mating Flange	1	M3	Polyamide (PA), Nylon	Tin	7 mm	0.2 in	5.08 mm	Screw - Rising Cage Clamp	0.2 mm²	2.5 mm²	300 V	Plug, Female Sockets	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Free Hanging (In-Line)	Green	0.591 in	15 mm	630 V
Phoenix Contact 1800934	12 A	2	2		30 AWG	12 AWG		1	M3		Tin	7 mm	0.2 in	5.08 mm	Screw - Rising Cage Clamp	0.2 mm²	2.5 mm²		Plug, Female Sockets	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Free Hanging (In-Line)	Black	0.591 in	15 mm	250 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 4 Pos 5mm pitch Plug 24-12 AWG Screw
