Technical Specifications
Parameters and characteristics for this part
| Specification | 2412F 0031000 |
|---|---|
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP), Polyolefin (PO) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Drain Wire |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Orange |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 8 |
| Ratings | UL Style CMR |
| Shield Coverage | 100 % |
| Shield Material | Aluminum |
| Shield Type | Foil |
| Usage | Network |
| Voltage | 300 V |
| Wire Gauge | 23 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
2412F Series
8 (4 Pair) Conductor Multi-Pair, Cat6+ Cable Orange 23 AWG Foil 1000.0' (304.8m)
Documents
Technical documentation and resources
