TMC2225-SA-T
ActiveAnalog Devices Inc./Maxim Integrated
IC MTR DRV 4.75-36V HTSSOP28
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TMC2225-SA-T
ActiveAnalog Devices Inc./Maxim Integrated
IC MTR DRV 4.75-36V HTSSOP28
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMC2225-SA-T | TMC2225 Series |
|---|---|---|
| Applications | General Purpose | General Purpose |
| Current - Output | 2 A | 1.4 - 2 A |
| Function | Driver - Fully Integrated, Control and Power Stage | Driver - Fully Integrated, Control and Power Stage |
| Motor Type - AC, DC | Universal | Universal, Brushed DC |
| Motor Type - Stepper | Bipolar | Bipolar |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 125 ¯C | 125 ¯C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Configuration | Step/Direction, SPI | Step/Direction, SPI, Half Bridge (2) |
| Package / Case | Exposed Pad, 28-TSSOP | Exposed Pad, 28-TSSOP, 28-VFQFN Exposed Pad |
| Package / Case [custom] | 4.4 mm | 4.4 mm |
| Package / Case [x] | 0.173 in | 0.173 in |
| Step Resolution | >256 | >256 |
| Step Resolution | - | 1 |
| Step Resolution | - | 0.00390625 |
| Supplier Device Package | 28-HTSSOP | 28-HTSSOP, 28-QFN (5x5) |
| Technology | Power MOSFET | Power MOSFET |
| Voltage - Load [Max] | 36 V | 36 V |
| Voltage - Load [Min] | 5.5 V | 5.5 V |
| Voltage - Supply [Max] | 5.25 V | 5.25 - 36 V |
| Voltage - Supply [Min] | 3 V | 3 - 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 4.65 | |
| 10 | $ 3.09 | |||
| 25 | $ 2.68 | |||
| 100 | $ 2.23 | |||
| 250 | $ 2.00 | |||
| 500 | $ 1.87 | |||
| 1000 | $ 1.76 | |||
| Digi-Reel® | 1 | $ 4.65 | ||
| 10 | $ 3.09 | |||
| 25 | $ 2.68 | |||
| 100 | $ 2.23 | |||
| 250 | $ 2.00 | |||
| 500 | $ 1.87 | |||
| 1000 | $ 1.76 | |||
| Tape & Reel (TR) | 4000 | $ 1.59 | ||
TMC2225 Series
IC MTR DRV 4.75-36V HTSSOP28
| Part | Mounting Type | Step Resolution | Operating Temperature [Min] | Operating Temperature [Max] | Motor Type - AC, DC | Voltage - Supply [Max] | Voltage - Supply [Min] | Technology | Motor Type - Stepper | Output Configuration | Package / Case | Package / Case [custom] | Package / Case [x] | Current - Output | Voltage - Load [Min] | Voltage - Load [Max] | Function | Applications | Supplier Device Package | Step Resolution [Max] | Step Resolution [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated TMC2225-SA-T | Surface Mount | >256 | -40 °C | 125 ¯C | Universal | 5.25 V | 3 V | Power MOSFET | Bipolar | SPI, Step/Direction | 28-TSSOP, Exposed Pad | 4.4 mm | 0.173 in | 2 A | 5.5 V | 36 V | Driver - Fully Integrated, Control and Power Stage | General Purpose | 28-HTSSOP | ||
Analog Devices Inc./Maxim Integrated TMC2225-SA | Surface Mount | -40 °C | 125 ¯C | Brushed DC | 36 V | 5.5 V | Power MOSFET | Bipolar | Half Bridge (2) | 28-VFQFN Exposed Pad | 1.4 A | 5.5 V | 36 V | Driver - Fully Integrated, Control and Power Stage | General Purpose | 28-QFN (5x5) | 1 | 0.00390625 |
Description
General part information
TMC2225 Series
Bipolar Motor Driver Power MOSFET SPI, Step/Direction, UART 28-HTSSOP
