Cable Assemblies

8A-05AMMM-SR7A10

Active

M SERIES SENSOR CONNECTOR, GUIDED M8, METAL, 1.5A, 05 PINS, MALE CONNECTOR, MALE CONTACT, RIGHT ANGLE, SCREW THREAD, OVERMOLDED,

Cable Assemblies

8A-05AMMM-SR7A10

Active

McGill Microwave Systems

M SERIES SENSOR CONNECTOR, GUIDED M8, METAL, 1.5A, 05 PINS, MALE CONNECTOR, MALE CONTACT, RIGHT ANGLE, SCREW THREAD, OVERMOLDED,

Specifications Series Pricing CAD Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	8A-05AMMM-SR7A10

1st Connector Gender	Male Pins
1st Connector Mounting Type	Free Hanging (In-Line)
1st Connector Number of Positions	5 positions
1st Connector Number of Positions Loaded	All
1st Connector Orientation	Keyed
1st Connector Shell Size - Insert	M8
1st Connector Type	Right Angle, Plug
2nd Connector Type	Wire Leads
Assembly Configuration	Standard
Cable Material	Polyvinyl Chloride (PVC)
Cable Type	Round
Color	Black
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Length	32.8 ft
Shielding	Unshielded
Usage	Industrial Environments

8A-05AMMM Series

Part	1st Connector Type	Usage	Color	1st Connector Mounting Type	Shielding	1st Connector Orientation	Cable Material	Cable Type	1st Connector Number of Positions	Assembly Configuration	1st Connector Shell Size - Insert	Ingress Protection Description	Ingress Protection IP Rating	2nd Connector Type	1st Connector Gender	Length	1st Connector Number of Positions Loaded
McGill Microwave Systems 8A-05AMMM-SR7A03	Plug Right Angle	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	9.84 ft	All
McGill Microwave Systems 8A-05AMMM-SR7A01	Plug Right Angle	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	3.28 ft	All
McGill Microwave Systems 8A-05AMMM-SL7A03	Plug	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	9.84 ft	All
McGill Microwave Systems 8A-05AMMM-SR7A10	Plug Right Angle	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	32.8 ft	All
McGill Microwave Systems 8A-05AMMM-SR7A05	Plug Right Angle	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	1.64 ft	All
McGill Microwave Systems 8A-05AMMM-SL7A02	Plug	Industrial Environments	Black	Free Hanging (In-Line)	Unshielded	Keyed	Polyvinyl Chloride (PVC)	Round	5 positions	Standard	M8	Dust Tight Waterproof	IP67	Wire Leads	Male Pins	6.56 ft	All

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$	Updated

Digikey	Bulk	10	$ 22.30	<6d
Newark	Each	10	$ 22.17	30d+
		25	$ 20.35
		50	$ 18.17
		100	$ 16.72
		250	$ 16.23

CAD

3D models and CAD resources for this part

Description

General part information

8A-05AMMM Series

Circular Cable Assembly Unshielded 32.8' (10.00m)

Documents

Technical documentation and resources

8A-05AMMM-SR7A10 | Datasheet
