BQ25883EVM
ActivePOWER MANAGEMENT IC
Deep-Dive with AI
Search across all available documentation for this part.
BQ25883EVM
ActivePOWER MANAGEMENT IC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ25883EVM | BQ25883 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Battery Pack Voltage | - | 9.2 V |
| Charge Current - Max | - | 2.2 A |
| Current - Charging | - | Constant |
| Fault Protection | - | Over Current, Over Voltage, Short Circuit, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Interface | - | I2C, USB |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 2 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 24-VFQFN Exposed Pad |
| Primary Attributes | Li-Ion / Li-Pol (2 Cells) | Li-Ion / Li-Pol (2 Cells) |
| Programmable Features | - | Current |
| Secondary Attributes | Test Points, On-Board LEDs | Test Points, On-Board LEDs |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-VQFN (4x4) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ25883 | BQ25883 |
| Voltage - Supply (Max) | - | 6.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | Box | 1 | $ 118.80 | |
| Digikey | Box | 1 | $ 118.80 | |
| Mouser Electronics | N/A | 1 | $ 131.66 | |
BQ25883 Series
I2C 2 cell 2A Boost battery charger for USB input in a WQFN package with Power Path
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Charge Current - Max [Max] | Fault Protection | Programmable Features | Interface | Current - Charging | Battery Pack Voltage | Battery Chemistry | Package / Case | Number of Cells | Voltage - Supply (Max) [Max] | Supplier Device Package | Mounting Type | Primary Attributes | Type | Secondary Attributes | Supplied Contents | Utilized IC / Part | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ25883RGER | 85 °C | -40 °C | 2.2 A | Over Current, Over Temperature, Over Voltage, Short Circuit | Current | I2C | Constant | 9.2 V | Lithium Ion/Polymer | 24-VFQFN Exposed Pad | 2 | 6.2 V | 24-VQFN (4x4) | Surface Mount | ||||||
Texas Instruments BQ25883RGET | 85 °C | -40 °C | 2.2 A | Over Current, Over Temperature, Over Voltage, Short Circuit | Current | I2C, USB | Constant | 9.2 V | Lithium Ion/Polymer | 24-VFQFN Exposed Pad | 2 | 6.2 V | 24-VQFN (4x4) | Surface Mount | ||||||
Texas Instruments BQ25883EVM | Li-Ion / Li-Pol (2 Cells) | Power Management | On-Board LEDs, Test Points | Board(s) | BQ25883 | Battery Charger |
Description
General part information
BQ25883 Series
The BQ25883 is a highly-integrated 2-A boost switch-mode battery charge management and system power path management device for 2-cell (2s) Li-Ion and Li-polymer battery. The BQ25883 has I2C control with OTG and power path.
The BQ25883 is a highly-integrated 2-A boost switch-mode battery charge management and system power path management device for 2-cell (2s) Li-Ion and Li-polymer battery. The BQ25883 has I2C control with OTG and power path.
Documents
Technical documentation and resources
