Q8R7BXXY02E

Active

APEM

LED PM INDICATOR RECESSED YLW

Search across all available documentation for this part.

Active

APEM

LED PM INDICATOR RECESSED YLW

Technical Specifications

Parameters and characteristics for this part

Specification	Q8R7BXXY02E

Ingress Protection	IP67
Lamp Color	Yellow
Lens Color	Yellow
Lens Size	T-1 3/4
Lens Size	5 mm
Lens Style	Round with Domed Top
Lens Transparency	Diffused
Millicandela Rating	40 mcd
Panel Cutout Dimensions [custom]	0.31 in
Panel Cutout Dimensions [custom]	7.87 mm
Panel Cutout Shape	Round
Termination Style	Wire Leads - 7.87" (200.00mm)
Type	LED
Viewing Angle	100 °
Voltage	2 V

Part	Voltage	Millicandela Rating	Ingress Protection	Lens Color	Viewing Angle	Panel Cutout Dimensions [custom]	Panel Cutout Dimensions [custom]	Termination Style	Type	Panel Cutout Shape	Lens Size	Lens Size	Lens Transparency	Lamp Color	Lens Style
APEM Q8R7BXXY02E	2 V	40 mcd	IP67	Yellow	100 °	0.31 in	7.87 mm	Wire Leads - 7.87" (200.00mm)	LED	Round	T-1 3/4	5 mm	Diffused	Yellow	Round with Domed Top

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Yellow Diffused 100° 2V 20mA Wire Leads - 7.87" (200.00mm)
