Connectors, Interconnects

1-968968-2

Active

TE Connectivity Raychem Cable Protection

CONN PLUG HSNG FMALE 3POS INLINE

Search across all available documentation for this part.

Connectors, Interconnects

Active

TE Connectivity Raychem Cable Protection

CONN PLUG HSNG FMALE 3POS INLINE

Technical Specifications

Parameters and characteristics for this part

Specification	1-968968-2

Connector Type	Plug Housing
Contact Shape	Circular
Contact Size	2.5 mm
Contact Type	Crimp
Fastening Type	Bayonet Lock
Features	Coupling Nut
Housing Color	Black
Ingress Protection	IP69K - Dust Tight, High Temp Water Jets, Waterproof
Material Flammability Rating	UL94 HB
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Operating Temperature [Max]	120 °C
Operating Temperature [Min]	-40 °C
Orientation	1
Shell Material	Polybutylene Terephthalate (PBT), Glass Filled
Shielding	Unshielded
Type	For Female Sockets

Part	Features	Housing Color	Contact Size	Note	Shell Material	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Ingress Protection	Material Flammability Rating	Shielding	Type	Contact Shape	Connector Type	Mounting Type	Fastening Type	Contact Type
TE Connectivity Raychem Cable Protection 1-968968-2	Coupling Nut	Black	2.5 mm	Contacts Not Included	Polybutylene Terephthalate (PBT) Glass Filled	1	-40 °C	120 °C	IP69K - Dust Tight High Temp Water Jets Waterproof	UL94 HB	Unshielded	For Female Sockets	Circular	Plug Housing	Free Hanging (In-Line)	Bayonet Lock	Crimp

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug Housing Free Hanging (In-Line) Coupling Nut

Technical documentation and resources

No documents available
