OSA-A3

Active

Omron Automation and Safety

RELAY TIME DELAY

Search across all available documentation for this part.

Active

Omron Automation and Safety

RELAY TIME DELAY

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	OSA-A3	- Series

Circuit	-	SPST-NO (1 Form A) x 2
Contact Rating @ Voltage	-	15 - 250 A
Delay Time	-	1 Min
Delay Time	-	1 - 24 Hrs
Function	-	Programmable (Multi-Function)
Mounting Type	-	DIN Rail, Chassis Mount
null		-
Relay Type	-	Mechanical Relay
Termination Style	-	Screw Terminal
Timing Adjustment Method	-	Up/Down Digit Keys
Timing Initiate Method	-	Input Voltage
Voltage - Supply	-	100 VAC
Voltage - Supply	-	240 VAC

RELAY TIME DELAY 24HR 15A 250V

Part	Timing Initiate Method	Voltage - Supply [Min]	Voltage - Supply [Max]	Delay Time [Min]	Delay Time [Max]	Function	Mounting Type	Timing Adjustment Method	Termination Style	Relay Type	Contact Rating @ Voltage	Circuit
Omron Automation and Safety H5F-KB	Input Voltage	100 VAC	240 VAC	1 Min	24 Hrs	Programmable (Multi-Function)	DIN Rail	Up/Down Digit Keys	Screw Terminal	Mechanical Relay	15 A, 250 VAC
Omron Automation and Safety BK-1080
Omron Automation and Safety H5S-FB	Input Voltage	100 VAC	240 VAC	1 Min	1 Year	Programmable (Multi-Function)	DIN Rail	Up/Down Digit Keys	Screw Terminal	Mechanical Relay	15 A, 250 VAC	SPST-NO (1 Form A) x 2
Omron Automation and Safety BK-1061
Omron Automation and Safety H5F-B	Input Voltage	100 VAC	240 VAC	1 Min	24 Hrs	Programmable (Multi-Function)		Up/Down Digit Keys	Screw Terminal	Mechanical Relay	15 A, 250 VAC
Omron Automation and Safety H5F-FB	Input Voltage	100 VAC	240 VAC	1 Min	24 Hrs	Programmable (Multi-Function)	Chassis Mount	Up/Down Digit Keys	Screw Terminal	Mechanical Relay	15 A, 250 VAC
Omron Automation and Safety OSA-A3
Omron Automation and Safety H5S-B	Input Voltage	100 VAC	240 VAC	1 Min	1 Year	Programmable (Multi-Function)		Up/Down Digit Keys	Screw Terminal	Mechanical Relay	15 A, 250 VAC	SPST-NO (1 Form A) x 2
Omron Automation and Safety H5L-A-GGS

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 329.29

General part information

Time Delay Relay Delay

Technical documentation and resources

No documents available
