MAXM17761EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EV KIT MAXM17761 1A BUCK
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAXM17761EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EV KIT MAXM17761 1A BUCK
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXM17761EVKIT# | MAXM17761 Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Board Type | Fully Populated | Fully Populated |
| Current - Output | 1 A | 1 A |
| Current - Output (Max) | - | 1 A |
| Features | - | OTP, UVLO, OCP |
| Frequency - Switching | 537 kHz | 537 kHz |
| Main Purpose | DC/DC, Step Down | DC/DC, Step Down |
| Mounting Type | - | Surface Mount |
| Number of Outputs | - | 1 |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Outputs and Type | Non-Isolated | Non-Isolated |
| Outputs and Type | 1 | 1 |
| Package / Case | - | 28-PowerBLGA Module |
| Regulator Topology | Buck | Buck |
| Size / Dimension | - | 0.11 in |
| Size / Dimension | - | 0.26 " |
| Size / Dimension | - | 10 mm |
| Size / Dimension | - | 0.39 " |
| Size / Dimension | - | 2.9 mm |
| Size / Dimension | - | 6.5 mm |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 10 |
| Supplier Device Package | - | 6.5 |
| Supplier Device Package | - | 28-LGA |
| Type | - | Non-Isolated PoL Module |
| Utilized IC / Part | MAXM17761 | MAXM17761 |
| Voltage - Input (Max) | - | 76 V |
| Voltage - Input (Min) | - | 4.5 V |
| Voltage - Input [Max] | 76 V | 76 V |
| Voltage - Input [Min] | 10 V | 10 V |
| Voltage - Output | 5 V | 5 V |
| Voltage - Output 1 | - | 0.8 V |
| Voltage - Output 1 | - | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 40.91 | |
MAXM17761 Series
EV KIT MAXM17761 1A BUCK
| Part | Main Purpose | Utilized IC / Part | Outputs and Type | Outputs and Type | Regulator Topology | Voltage - Output | Voltage - Input [Max] | Voltage - Input [Min] | Supplied Contents | Frequency - Switching | Board Type | Current - Output | Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Number of Outputs | Applications | Mounting Type | Type | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Voltage - Input (Min) [Min] | Package / Case | Supplier Device Package [y] | Supplier Device Package [x] | Supplier Device Package | Current - Output (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXM17761EVKIT# | DC/DC, Step Down | MAXM17761 | Non-Isolated | 1 | Buck | 5 V | 76 V | 10 V | Board(s) | 537 kHz | Fully Populated | 1 A | ||||||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17761ALI# | 76 V | 0.11 in | 0.26 " | 10 mm | 0.39 " | 2.9 mm | 6.5 mm | 1 | ITE (Commercial) | Surface Mount | Non-Isolated PoL Module | 0.8 V | 5 V | 4.5 V | 28-PowerBLGA Module | 10 | 6.5 | 28-LGA | 1 A | 125 °C | -40 °C | OCP, OTP, UVLO | ||||||||||||
Analog Devices Inc./Maxim Integrated MAXM17761ALI#T | 76 V | 0.11 in | 0.26 " | 10 mm | 0.39 " | 2.9 mm | 6.5 mm | 1 | ITE (Commercial) | Surface Mount | Non-Isolated PoL Module | 0.8 V | 5 V | 4.5 V | 28-PowerBLGA Module | 10 | 6.5 | 28-LGA | 1 A | 125 °C | -40 °C | OCP, OTP, UVLO |
Description
General part information
MAXM17761 Series
MAXM17761 Himalaya DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Documents
Technical documentation and resources
