PE42451MLIAA-Z

Active

pSemi Corporation

IC RF SWITCH SP5T 4GHZ 24QFN

Search across all available documentation for this part.

Active

pSemi Corporation

IC RF SWITCH SP5T 4GHZ 24QFN

Technical Specifications

Parameters and characteristics for this part

IC RF SWITCH SP5T 4GHZ 24QFN

Part	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	RF Type	Supplier Device Package	Topology	Circuit	IIP3	Impedance	Test Frequency	Frequency Range [Max]	Frequency Range [Min]	Insertion Loss	Features	Isolation	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	P1dB
pSemi Corporation PE42451MLIAA-Z	Surface Mount	85 °C	-40 °C	General Purpose	24-QFN (4x4)	Absorptive	SP5T	58 dBm	50 Ohms	4 GHz	4 GHz	450 MHz	2.25 dB	DC Blocked	50 dB	24-WFQFN Exposed Pad	2.7 V	3.3 V	35 dBm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	3000	$ 3.73

General part information

RF Switch IC General Purpose SP5T 4 GHz 50Ohm 24-QFN (4x4)
