Specification	TMV 2-12159HI

Applications	ITE (Commercial)
Current - Output (Max) Options	66mA, 110mA
Efficiency	81 %
Features	SCP
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package Leads	4 Leads
Package Name	7-SIP Module
Power (Watts)	2 w
Size / Dimension Height	0.4 in
Size / Dimension Length	0.77 in
Size / Dimension Width	0.3 in
Type	Isolated Module
Voltage - Input (Max)	13.2 V
Voltage - Input (Min)	10.8 V
Voltage - Isolation	5.2 kV
Voltage - Output 1	15 V
Voltage - Output 2	-9 V

TMV 2 Series

Part	Power (Watts)	Package Leads	Package Name	Voltage - Input (Max)	Efficiency	Voltage - Output 1	Mounting Type	Voltage - Input (Min)	Voltage - Isolation	Applications	Number of Outputs	Features	Current - Output (Max)	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Operating Temperature (Max)	Operating Temperature (Min)	Type	Voltage - Output 2	Current - Output (Max) Options
Traco Power TMV 2-1212SHI	2 w	4 Leads	7-SIP Module	13.2 V	83 %	12 V	Through Hole	10.8 V	5.2 kV	ITE (Commercial)	1	SCP	168 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module
Traco Power TMV 2-1515DHI	2 w	5 Leads	7-SIP	16.5 V	82 %	15 V	Through Hole	13.5 V	5.2 kV	ITE (Commercial)	2	SCP	66 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module	-15 V
Traco Power TMV 2-1509SHI	2 w	4 Leads	7-SIP Module	16.5 V	83 %	9 V	Through Hole	13.5 V	5.2 kV	ITE (Commercial)	1	SCP	222 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module
Traco Power TMV 2-1205DHI	2 w	5 Leads	7-SIP	13.2 V	79 %	5 V	Through Hole	10.8 V	5.2 kV	ITE (Commercial)	2	SCP	200 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module	-5 V
Traco Power TMV 2-1203SHI	1.7 W	4 Leads	7-SIP Module	13.2 V	76 %	3.3 V	Through Hole	10.8 V	5.2 kV	ITE (Commercial)	1	SCP	500 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module
Traco Power TMV 2-1515SHI	2 w	4 Leads	7-SIP Module	16.5 V	85 %	15 V	Through Hole	13.5 V	5.2 kV	ITE (Commercial)	1	SCP	132 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module
Traco Power TMV 2-24159HI	2 w	4 Leads	7-SIP Module	26.4 V	81 %	15 V	Through Hole	21.6 V	5.2 kV	ITE (Commercial)	2	SCP		0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module	-9 V	110mA 66mA
Traco Power TMV 2-0503SHI	1.7 W	4 Leads	7-SIP Module	5.5 V	74 %	3.3 V	Through Hole	4.5 V	5.2 kV	ITE (Commercial)	1	SCP	500 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module
Traco Power TMV 2-12159HI	2 w	4 Leads	7-SIP Module	13.2 V	81 %	15 V	Through Hole	10.8 V	5.2 kV	ITE (Commercial)	2	SCP		0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module	-9 V	110mA 66mA
Traco Power TMV 2-1505SHI	2 w	4 Leads	7-SIP Module	16.5 V	79 %	5 V	Through Hole	13.5 V	5.2 kV	ITE (Commercial)	1	SCP	400 mA	0.4 in	0.77 in	0.3 in	85 °C	-40 °C	Isolated Module

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

TMV 2-12159HI | Datasheet
