MA4P1450-1091T
ActiveMACOM Technology Solutions
RF DIODE PIN 100V 10W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MA4P1450-1091T
ActiveMACOM Technology Solutions
RF DIODE PIN 100V 10W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MA4P1450-1091T |
|---|---|
| Capacitance @ Vr, F | 2.5 pF |
| Diode Type | PIN - Single |
| Operating Temperature [Max] | 175 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 2-SMD |
| Power Dissipation (Max) [Max] | 10 W |
| Resistance @ If, F | 750 mOhm |
| Voltage - Peak Reverse (Max) [Max] | 100 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 12.49 | |
| 10 | $ 11.48 | |||
| 25 | $ 11.01 | |||
| 100 | $ 10.47 | |||
| Digi-Reel® | 1 | $ 12.49 | ||
| 10 | $ 11.48 | |||
| 25 | $ 11.01 | |||
| 100 | $ 10.47 | |||
| Tape & Reel (TR) | 500 | $ 10.47 | ||
Description
General part information
MA4P1450 Series
RF Diode PIN - Single 100V 10 W
Documents
Technical documentation and resources
