T31SN12008NMFA

Active

Delta Electronics

DC DC CONVERTER 3.3-16.5V 100W

Search across all available documentation for this part.

Active

Delta Electronics

DC DC CONVERTER 3.3-16.5V 100W

Technical Specifications

Parameters and characteristics for this part

Specification	T31SN12008NMFA

Applications	ITE (Commercial)
Control Features	Active Low, Enable
Current - Output (Max) [Max]	8 A
Efficiency	96.5 %
Features	Remote On/Off, Adjustable Output, Remote Sense
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Power (Watts)	100 W
Size / Dimension [x]	23.4 mm
Size / Dimension [x]	0.92 in
Size / Dimension [y]	0.75 in
Size / Dimension [y]	19.1 mm
Size / Dimension [z]	10.1 mm
Size / Dimension [z]	0.4 "
Supplier Device Package	Thirty-Second Brick
Type	Non-Isolated PoL Module
Voltage - Input (Max) [Max]	53 V
Voltage - Input (Min) [Min]	9 V
Voltage - Output 1 [Max]	16.5 V
Voltage - Output 1 [Min]	3.3 V

DC DC CONVERTER 3.3-16.5V 100W

Part	Type	Control Features	Voltage - Input (Max) [Max]	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Power (Watts)	Number of Outputs	Package / Case	Voltage - Input (Min) [Min]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current - Output (Max) [Max]	Applications	Supplier Device Package	Features
Delta Electronics T31SN12008NMFA	Non-Isolated PoL Module	Active Low, Enable	53 V	3.3 V	16.5 V	100 W	1	Module	9 V	23.4 mm	0.92 in	10.1 mm	0.75 in	0.4 "	19.1 mm	96.5 %	85 °C	-40 °C	Surface Mount	8 A	ITE (Commercial)	Thirty-Second Brick	Adjustable Output, Remote On/Off, Remote Sense

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Non-Isolated PoL Module DC DC Converter 1 Output 3.3 ~ 16.5V 8A 9V - 53V Input
