74HC244FPDVEL-E

Active

Renesas Electronics Corporation

IC BUFFER NON-INVERT 6V

Search across all available documentation for this part.

Active

Renesas Electronics Corporation

IC BUFFER NON-INVERT 6V

Technical Specifications

Parameters and characteristics for this part

Specification	74HC244FPDVEL-E

Current - Output High, Low [custom]	7.8 mA
Current - Output High, Low [custom]	7.8 mA
Logic Type	Buffer, Non-Inverting
Number of Bits per Element	4
Number of Elements	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Output Type	3-State
Voltage - Supply [Max]	6 V
Voltage - Supply [Min]	2 V

IC BUFFER NON-INVERT 6V

Part	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Min]	Voltage - Supply [Max]	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Number of Elements	Number of Bits per Element	Logic Type
Renesas Electronics Corporation 74HC244FPDVEL-E	3-State	125 °C	-55 °C	2 V	6 V	7.8 mA	7.8 mA	2	4	Buffer, Non-Inverting

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	464	$ 0.65

General part information

Buffer, Non-Inverting 2 Element 4 Bit per Element 3-State Output

Technical documentation and resources

No documents available
