AB3X2X6W
ObsoleteToshiba Semiconductor and Storage
FERRITE CORE SOLID 1.5MM
Deep-Dive with AI
Search across all available documentation for this part.
AB3X2X6W
ObsoleteToshiba Semiconductor and Storage
FERRITE CORE SOLID 1.5MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AB3X2X6W |
|---|---|
| Inner Dimension [diameter] | 0.059 in |
| Inner Dimension [diameter] | 1.5 mm |
| Length [x] | 7.5 mm |
| Length [x] | 0.295 in |
| Mounting Type | Free Hanging |
| Outer Dimension [diameter] | 4 mm |
| Outer Dimension [diameter] | 0.157 in |
| Type | Round |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AB3X2X6 Series
Solid Free Hanging Ferrite Core ID 0.059" Dia (1.50mm) OD 0.157" Dia (4.00mm) Length 0.295" (7.50mm)
Documents
Technical documentation and resources
No documents available
