89901 E4X1000

Active

Belden Inc.

MULTI-PAIR 8CON 20AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

MULTI-PAIR 8CON 20AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	89901 E4X1000

Cable Type	Multi-Pair
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP), Foam Fluorinated Ethylene-Propylene (FFEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	28
Conductor Strand [custom]	7
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.37 in
Jacket (Insulation) Diameter [diameter]	9.4 mm
Jacket (Insulation) Material	Polyvinylidene Fluoride (PVDF), Plenum
Jacket (Insulation) Thickness	0.406 mm
Jacket (Insulation) Thickness	0.016 in
Jacket Color	Gray
Length	1000 ft
Length	304.8 m
Number of Conductors	8
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-20 C
Shield Coverage	95 %, 100 %
Shield Material	Copper, Tinned, Aluminum
Shield Type	Foil, Braid
Voltage	300 V
Wire Gauge	20 AWG

Part	Features	Operating Temperature [Max]	Operating Temperature [Min]	Conductor Insulation	Shield Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Voltage	Shield Type	Length	Length	Wire Gauge	Shield Coverage	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Material
Belden Inc. 89901 E4X1000	Drain Wire	150 °C	-20 C	Fluorinated Ethylene-Propylene (FEP) Foam Fluorinated Ethylene-Propylene (FFEP)	Aluminum Copper Tinned	0.37 in	9.4 mm	Gray	Plenum Polyvinylidene Fluoride (PVDF)	0.406 mm	0.016 in	Multi-Pair	300 V	Braid Foil	1000 ft	304.8 m	20 AWG	95 % 100 %	8	28	7	Copper Tinned

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 15.79

General part information

8 (4 Pair Twisted) Conductor Multi-Pair Cable Gray 20 AWG Foil, Braid 1000.0' (304.8m)
