LM2794TLX

Active

National Semiconductor

IC LED DRV RGLTR PWM 20MA 14USMD

Search across all available documentation for this part.

Active

National Semiconductor

IC LED DRV RGLTR PWM 20MA 14USMD

Technical Specifications

Parameters and characteristics for this part

Specification	LM2794TLX

Applications	Backlight
Current - Output / Channel [custom]	20 mA
Dimming	Analog, PWM
Internal Switch(s)	True
Mounting Type	Surface Mount
Number of Outputs	4
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-30 °C
Package / Case	14-WFBGA
Supplier Device Package	14-µSMD
Supplier Device Package [x]	2.1
Supplier Device Package [y]	2.4
Topology	Switched Capacitor (Charge Pump)
Type	DC DC Regulator
Voltage - Output	3.8 V
Voltage - Supply (Max)	5.5 V

Part	Voltage - Output	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Type	Current - Output / Channel [custom]	Mounting Type	Applications	Number of Outputs	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Topology	Dimming	Voltage - Supply (Max)	Internal Switch(s)
National Semiconductor LM2794TLX	3.8 V	-30 °C	85 °C	14-WFBGA	DC DC Regulator	20 mA	Surface Mount	Backlight	4	2.1	2.4	14-µSMD	Switched Capacitor (Charge Pump)	Analog PWM	5.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	650	$ 0.46

General part information

LED Driver IC 4 Output DC DC Regulator Switched Capacitor (Charge Pump) Analog, PWM Dimming 20mA 14-µSMD (2.1x2.4)
