SFEM010GB1ED1TO-I-5E-31P-STD

Active

SWISSBIT

FLASH MEMORY, 3D TLC NAND, 10 GB, BGA, 100 PINS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Technical Data Sheet EN

SFEM010GB1ED1TO-I-5E-31P-STD

Active

SWISSBIT

FLASH MEMORY, 3D TLC NAND, 10 GB, BGA, 100 PINS

Deep-Dive with AI

DocumentsDatasheet Technical Data Sheet EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	SFEM010GB1ED1TO-I-5E-31P-STD	SFEM010 Series

Clock Frequency	200 MHz	200 MHz
Memory Format	FLASH	FLASH
Memory Interface	eMMC	eMMC
Memory Organization	10 G	10 G
Memory Size	80 Gbit	80 Gbit
Memory Type	Non-Volatile	Non-Volatile
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	100-LBGA	100-LBGA, 153-TFBGA
Supplier Device Package	100-BGA (14x18)	100-BGA (14x18), 153-BGA
Supplier Device Package	-	13
Supplier Device Package	-	11.5
Technology	FLASH - NAND (pSLC)	FLASH - NAND (pSLC), FLASH - NAND
Voltage - Supply [Max]	3.6 V	3.6 V
Voltage - Supply [Min]	2.7 V	2.7 V

SFEM010 Series

FLASH MEMORY, 3D TLC NAND, 10 GB, BGA, 100 PINS

Part	Supplier Device Package	Memory Format	Mounting Type	Technology	Memory Organization	Memory Interface	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Min]	Voltage - Supply [Max]	Memory Type	Memory Size	Clock Frequency	Package / Case	Supplier Device Package [y]	Supplier Device Package [x]
SWISSBIT SFEM010GB1ED1TO-I-5E-31P-STD	100-BGA (14x18)	FLASH	Surface Mount	FLASH - NAND (pSLC)	10 G	eMMC	85 °C	-40 °C	2.7 V	3.6 V	Non-Volatile	80 Gbit	200 MHz	100-LBGA
SWISSBIT SFEM010GB1ED1TO-I-5E-11P-STD	153-BGA	FLASH	Surface Mount	FLASH - NAND	10 G	eMMC	85 °C	-40 °C	2.7 V	3.6 V	Non-Volatile	80 Gbit	200 MHz	153-TFBGA	13	11.5

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 15.03
		10	$ 13.92
		25	$ 13.48
		40	$ 13.26
		80	$ 13.06

Description

General part information

SFEM010 Series

SFEM010GB1ED1TO-I-5E-31P-STD is an EM-30 series industrial e·MMC memory. It equals wear levelling of static and dynamic data. The wear levelling assures that dynamic data as well as static data is balanced evenly across the memory. With that the maximum write endurance of the device is ensured. The interruptible background process maintains the user data for read disturb effects or retention degradation due to high temperature effects. Diagnostic features with device health report according to e·MMC Spec 5.1, and detailed lifetime monitor data (Swissbit proprietary, accessible through standard e·MMC commands). Enhanced Mode (pSLC) with higher write performance and endurance than 3D TLC configured products (EM-30). Ideal for application like POS/POI, PLC, IoT, gaming, medical and use as general boot medium for embedded applications.
