BT57-E51D200000000

Active

Sifam Tinsley Instrumentation Inc

DIG PROCESS METER;0-200VDC,120V

Search across all available documentation for this part.

Active

Sifam Tinsley Instrumentation Inc

DIG PROCESS METER;0-200VDC,120V

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	BT57-E51D200000000	BT57-E Series

Display Characters - Height [z]	18.1 mm	14 - 18.1 mm
Display Characters - Height [z]	0.713 in	0.551 - 0.713 in
Display Type	LCD - Red Characters	LCD - Red Characters
Features	Scaling Meter	Scaling Meter
Ingress Protection	IP54 - Dust Protected, Water Resistant	IP54 - Dust Protected, Water Resistant
Measuring Range	-	0.2 VDC
Measuring Range	-	0 V
Measuring Type	Voltage	Voltage
Number of Characters Per Row	4.5	4.5
Panel Cutout Dimensions [x]	92.8 mm	92.8 mm
Panel Cutout Dimensions [y]	44.1 mm	44.1 mm
Termination Style	Plug In Screw Terminals	Plug In Screw Terminals, Screw Terminal
Type	Voltmeter	Voltmeter
Voltage - Supply	110 VAC/DC	110 VAC/DC
Weight	1.1 lbs	1.1 lbs
Weight	499 g	499 g

DIG PROCESS METER;0-200VDC,120V

Part	Features	Weight	Weight	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Type	Voltage - Supply	Measuring Type	Termination Style	Number of Characters Per Row	Ingress Protection	Display Characters - Height [z]	Display Characters - Height [z]	Display Type	Measuring Range [Max]	Measuring Range [Min]
Sifam Tinsley Instrumentation Inc BT57-E51D200000000	Scaling Meter	1.1 lbs	499 g	92.8 mm	44.1 mm	Voltmeter	110 VAC/DC	Voltage	Plug In Screw Terminals	4.5	IP54 - Dust Protected, Water Resistant	18.1 mm	0.713 in	LCD - Red Characters
Sifam Tinsley Instrumentation Inc BT57-E40D200000000				92.8 mm	44.1 mm	Voltmeter	110 VAC/DC	Voltage	Screw Terminal	4.5		14 mm	0.551 in	LCD - Red Characters	0.2 VDC	0 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Retail Package	1	$ 125.00

General part information

Voltmeter LCD - Red Characters Display Panel Mount
