PEH169VH3470QB2

Active

KEMET

CAP ALUM 470UF 400V SCREW CHAS M

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 470UF 400V SCREW CHAS M

Technical Specifications

Parameters and characteristics for this part

Specification	PEH169VH3470QB2

Applications	General Purpose
Capacitance	470 µF
ESR (Equivalent Series Resistance)	160 mOhm
Height - Seated (Max) [Max] [z]	74.5 mm
Height - Seated (Max) [Max] [z]	2.933 in
Lead Spacing	0.866 in
Lead Spacing	22 mm
Lifetime @ Temp.	5000 Hrs
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Screw Terminals
Polarization	Polar
Ripple Current @ High Frequency	13.5 A
Ripple Current @ Low Frequency	4 A
Size / Dimension [diameter]	2.031 in
Size / Dimension [diameter]	51.6 mm
Tolerance [Max]	30 %
Tolerance [Min]	-10 %
Voltage - Rated	400 V

Part	Capacitance	Tolerance [Min]	Tolerance [Max]	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Min]	Polarization	Ripple Current @ Low Frequency	Package / Case	Ripple Current @ High Frequency	Applications	Lead Spacing	Lead Spacing	ESR (Equivalent Series Resistance)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Lifetime @ Temp.
KEMET PEH169VH3470QB2	470 µF	-10 %	30 %	400 V	85 °C	-40 °C	Polar	4 A	Radial Can - Screw Terminals	13.5 A	General Purpose	0.866 in	22 mm	160 mOhm	74.5 mm	2.933 in	2.031 in	51.6 mm	Chassis Mount	5000 Hrs

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

470 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 160mOhm @ 100Hz 5000 Hrs @ 85°C
