SF2294E
ObsoleteMurata Electronics
FILTER SAW 922.5MHZ 6SMD
SF2294E
ObsoleteMurata Electronics
FILTER SAW 922.5MHZ 6SMD
Description
General part information
SF22 Series
922.5MHz Frequency General Purpose RF SAW Filter (Surface Acoustic Wave) 2.7dB 5MHz Bandwidth 6-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | SF2294E |
|---|---|
| Applications | General Purpose |
| Bandwidth | 5 MHz |
| Frequency - Center | 922.5 MHz |
| Height (Max) | 0.054 in |
| Insertion Loss | 2.7 dB |
| Mounting Type | Surface Mount |
| Package / Case | No Lead, 6-SMD |
| Size / Dimension Length | 0.118 in |
| Size / Dimension Width | 0.118 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
