1336A 0061640

Active

Belden Inc.

CABLE 2COND 14AWG BLUE SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 14AWG BLUE SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	1336A 0061640

Cable Type	Multi-Conductor
Conductor Insulation	Polyolefin (PO)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	21.5 AWG
Features	Rip Cord, UV Resistant, Oil Resistant, Drain Wire
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Blue
Length [x]	500 m
Length [x]	1640.4 ft
Number of Conductors	2
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-30 ░C
Shield Coverage	100 %, 65 %
Shield Material	Copper, Tinned, Aluminum
Shield Type	Foil, Braid
Voltage	300 V
Wire Gauge	13.5 AWG

Part	Conductor Insulation	Conductor Material	Operating Temperature [Min]	Operating Temperature [Max]	Shield Material	Wire Gauge	Voltage	Shield Coverage	Shield Type	Cable Type	Jacket (Insulation) Material	Features	Length [x]	Length [x]	Jacket Color	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]
Belden Inc. 1336A 0061640	Polyolefin (PO)	Copper Tinned	-30 ░C	90 °C	Aluminum Copper Tinned	13.5 AWG	300 V	65 % 100 %	Braid Foil	Multi-Conductor	Poly-Vinyl Chloride (PVC)	Drain Wire Oil Resistant Rip Cord UV Resistant	500 m	1640.4 ft	Blue	2	7	21.5 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 16.06

General part information

2 (1 Pair) Conductor Multi-Conductor Cable Blue 14 AWG Foil, Braid 1640.4' (500.0m)

Technical documentation and resources
