Q-2O04L000D018i

Active

Amphenol Custom Cable

CBL ASSY NTYPE-TNC PLUG-JACK 18"

Deep-Dive with AI

Search across all available documentation for this part.

Q-2O04L000D018i

Active

Amphenol Custom Cable

CBL ASSY NTYPE-TNC PLUG-JACK 18"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2O04L000D018i

1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	TNC Jack
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Female
Cable Type	LMR 195
Color	Black
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length [x]	457.2 mm
Length [x]	457.2 mm
Overall Impedance	50 Ohms

Q-2O04L0 Series

Part	2nd Contact Gender	Length	Length	Length	2nd Connector Mounting Type	Frequency - Max [Max]	Features	1st Connector Mounting Type	Cable Type	Overall Impedance	2nd Connector	1st Contact Gender	Color	Length [x]	Length [x]	Length [x]
Amphenol Custom Cable Q-2O04L000D003M	Female	3 m	118.1 in	9.8 '	Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D002M	Female	2 m	78.7 in	6.6 ft	Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D084i	Female	2.1 m	84 in	7 ft	Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D024i	Female	609.6 mm	24 "		Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D048i	Female	1200 mm	48 in	4 ft	Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D009i	Female	228.6 mm	9 "		Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D072i	Female	1.8 m	72 in	6 ft	Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black
Amphenol Custom Cable Q-2O04L000D.25M	Female				Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black	9.843 "	250 mm
Amphenol Custom Cable Q-2O04L000D018i	Female				Free Hanging (In-Line)	6000 MHz	Shielded	Free Hanging (In-Line)	LMR 195	50 Ohms	TNC Jack	Male	Black		457.2 mm	457.2 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 54.91
		25	$ 53.85
		50	$ 52.79
		100	$ 51.73
		250	$ 50.67

Description

General part information

Q-2O04L0 Series

Cable Assembly Coaxial N-Type to TNC LMR 195 18.00" (457.20mm)

Documents

Technical documentation and resources

No documents available
