1211-20016
ActiveMcGill Microwave Systems
SMP MALE PCB SURFACE MOUNT CONNECTOR (GLASS SEAL), FD /INDIVIDUAL - TRAY (PACK FILL QTY: 100)
1211-20016
ActiveMcGill Microwave Systems
SMP MALE PCB SURFACE MOUNT CONNECTOR (GLASS SEAL), FD /INDIVIDUAL - TRAY (PACK FILL QTY: 100)
Description
General part information
1211-20 Series
SMP Connector Plug, Male Pin 50 Ohms Surface Mount Solder
Technical Specifications
Parameters and characteristics for this part
| Specification | 1211-20016 |
|---|---|
| Body Finish | Gold |
| Body Material | Steel |
| Center Contact Plating | Gold |
| Connector Style | SMP |
| Connector Type | Male Pin, Plug |
| Contact Termination | Solder |
| Dielectric Material | Glass |
| Fastening Type | Snap-On |
| Features | Full Detent |
| Frequency - Max | 26.5 GHz |
| Housing Color | Gold |
| Impedance | 50 Ohm |
| Mating Cycles | 100 cycles |
| Mounting Type | Surface Mount |
| Number of Ports | 1 |
| Operating Temperature (Max) | 165 °C |
| Operating Temperature (Min) | -65 °C |
| Shield Termination | Solder |
