CPC Series

Part	Termination	Number of Positions	Contact Finish - Mating	Connector Type	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Mounting Type	Shell Material	Orientation	Shielding	Material Flammability Rating	Mounting Feature	Fastening Type	Color	Operating Temperature (Min)	Operating Temperature (Max)	Voltage Rating	Voltage Rating (Type)	Primary Material	Contact Material	Contact Finish Thickness - Mating
TE Connectivity AMP Connectors 3-206934-1	Solder	37 pos	Gold	Male Pins Receptacle	23	37
TE Connectivity AMP Connectors 206934-9	Solder	37 pos	Gold	Male Pins Receptacle	23	37	Panel Mount Through Hole	Thermoplastic	A	Unshielded	UL94 V-0	Flange	Threaded	Black	-55 °C	105 °C	250 V	DC	Plastic	Brass
TE Connectivity AMP Connectors 1-206934-3	Solder	37 pos	Gold	Male Pins Receptacle	23	37	Panel Mount Through Hole	Thermoplastic	A	Unshielded	UL94 V-0	Flange	Threaded	Black	-55 °C	105 °C	250 V	DC	Plastic	Brass
TE Connectivity AMP Connectors 206934-5	Solder	37 pos	Gold	Male Pins Receptacle	23	37	Panel Mount Through Hole	Thermoplastic	A		UL94 V-0	Flange	Threaded	Black	-55 °C	105 °C	250 V	DC	Plastic	Brass	30 µin
TE Connectivity AMP Connectors 206934-7	Solder	37 pos	Gold	Male Pins Receptacle	23	37	Panel Mount Through Hole	Thermoplastic	A		UL94 V-0	Flange	Threaded	Black	-55 °C	105 °C	250 V	DC	Plastic	Brass	30 µin
TE Connectivity AMP Connectors 2-206934-7

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
