XEGAGR-H0-0000-000-000000U2001
ActiveCreeLED, Inc.
XLAMP XEG GREEN LED
XEGAGR-H0-0000-000-000000U2001
ActiveCreeLED, Inc.
XLAMP XEG GREEN LED
Description
General part information
XEGAGR Series
LED Lighting Color XLamp® XE-G Green 530nm 3-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | XEGAGR-H0-0000-000-000000U2001 |
|---|---|
| Color | Green |
| Current - Max | 3 A |
| Current - Test | 1 A |
| Height - Seated (Max) | 0.044 in |
| Luminous Flux | 300 lm |
| Mounting Type | Surface Mount |
| Package / Case | No Lead, 3-SMD |
| Package Name | 3-SMD |
| Size / Dimension Length | 0.081 in |
| Size / Dimension Width | 0.063 in |
| Temperature - Test | 25 °C |
| Viewing Angle | 125 ° |
| Voltage - Forward (Vf) (Typ) | 3.05 V |
| Wavelength | 530 nm |
