Part	Voltage - Isolation	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Efficiency	Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Output 1	Mounting Type	Applications	Power (Watts)	Number of Outputs	Current - Output 1	Features	Voltage - Input (AC) Minimum	Voltage - Input	Voltage - Input (AC) Maximum	Approval Agency	Minimum Load Required
Bel Fuse Inc. ULP180-0358	3 kV	0.75 in	4 in	2.5 in	92 %	Open Frame	70 °C	-40 °C	58 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	2.07 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL
Bel Fuse Inc. ULP180-0058	3 kV	0.75 in	4 in	2.5 in	92 %	Open Frame	70 °C	-40 °C	58 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	2.07 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL	No
Bel Fuse Inc. ULP180-1012	3 kV	0.75 in	4 in	2 in	88 %	Open Frame	70 °C	-40 °C	12 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	10 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL
Bel Fuse Inc. ULP180-0315	3 kV	0.75 in	4 in	2.5 in	88 %	Open Frame	70 °C	-40 °C	15 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	8 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL	No
Bel Fuse Inc. ULP180-0348	3 kV	0.75 in	4 in	2.5 in	92 %	Open Frame	70 °C	-40 °C	48 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	2.5 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL	No
Bel Fuse Inc. ULP180-0024	3 kV	0.75 in	4 in	2.5 in	90 %	Open Frame	70 °C	-40 °C	24 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	5 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL	No
Bel Fuse Inc. ULP180-1324	3 kV	0.75 in	4 in	2 in	90 %	Open Frame	70 °C	-40 °C	24 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	5 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL
Bel Fuse Inc. ULP180-1048	3 kV	0.75 in	4 in	2 in	92 %	Open Frame	70 °C	-40 °C	48 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	2.5 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL
Bel Fuse Inc. ULP180-0015	3 kV	0.75 in	4 in	2.5 in	88 %	Open Frame	70 °C	-40 °C	15 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	8 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL	No
Bel Fuse Inc. ULP180-0330	3 kV	0.75 in	4 in	2.5 in	90 %	Open Frame	70 °C	-40 °C	30 V	Chassis Mount	ITE (Commercial)	120 W 180 W	1	4 A	Adjustable Output PFC Standby Output Universal Input	80 V	390 VDC	264 V	CB CE cUL NEMKO UL

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet
