MMDS-031 Series
Manufacturer: Omnetics
Catalog
CABLE ASSY D-MIC-D 31P 457.2MM
| Part | Color | Shielding | Contact Finish Thickness | Contact Finish Thickness | Type | Length [x] | Length [x] | Contact Finish | 1st Connector | Number of Positions | 2nd Connector | Shell Material, Finish | Contact Form | Connector Style | Contact Material | Mounting Type | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Dielectric Material | Number of Rows | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Flange Feature | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omnetics | Individual Multiple | Unshielded | 50 µin | 1.27 µm | D-Type Micro-D | 457.2 mm | 1.5 ft | Gold | Female Sockets Receptacle | 31 | Individual Wire Leads | |||||||||||||||
Omnetics | 50 µin | 1.27 µm | Gold | 31 | Aluminum Electroless Nickel Plated | Stamped | D-Type Micro-D | Copper Alloy | Free Hanging (In-Line) | Receptacle Female Sockets | -55 °C | 125 °C | Signal | Thermoplastic | 2 | 0.05 | 0.05 | Housing/Shell (Unthreaded) | 3 A |
