Micro-Fit+ Versa Color Vertical Header, Through Hole, 3.00mm Pitch, Dual Row, 10 Circuits, 0.38µm Gold (Au) Plating, Glow-Wire Capable, Yellow, Tray
Micro-Fit+ Versa Color Vertical Header, Through Hole, 3.00mm Pitch, Dual Row, 10 Circuits, 0.38µm Gold (Au) Plating, Glow-Wire Capable, Yellow, Tray
Micro-Fit+ Versa Color Vertical Header, Through Hole, 3.00mm Pitch, Dual Row, 10 Circuits, 0.38µm Gold (Au) Plating, Glow-Wire Capable, Yellow, Tray
| Part | Connector Type | Contact Material | Operating Temperature (Min) | Operating Temperature (Max) | Fastening Type | Contact Finish Thickness - Mating | Contact Shape | Termination | Number of Positions | Insulation Material | Mounting Type | Features | Contact Finish - Mating | Current Rating | Current Rating | Style | Row Spacing - Mating | Material Flammability Rating | Contact Length - Post | Contact Type | Insulation Height | Number of Positions Loaded | Shrouding | Insulation Color | Contact Finish - Post | Pitch - Mating | Number of Rows | Voltage Rating | Voltage Rating (Type) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 15 µin | Square | Solder | 10 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Red | Tin | 0.118 in | 2 | 600 V | DC |
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | Square | Solder | 4 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide Pick and Place | Tin | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Black | Tin | 0.118 in | 2 | 600 V | DC | |
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 15 µin | Square | Solder | 4 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Blue | Tin | 0.118 in | 2 | 600 V | DC |
Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 30 µin | Square | Solder | 4 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Blue | Tin | 0.118 in | 2 | 600 V | DC |
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | Square | Solder | 8 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Tin | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Natural | Tin | 0.118 in | 2 | 600 V | DC | |
Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 15 µin | Square | Solder | 8 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Natural | Tin | 0.118 in | 2 | 600 V | DC |
Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | Square | Solder | 12 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Tin | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Natural | Tin | 0.118 in | 2 | 600 V | DC | |
Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 15 µin | Square | Solder | 6 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Red | Tin | 0.118 in | 2 | 600 V | DC |
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | Square | Solder | 4 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Tin | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Natural | Tin | 0.118 in | 2 | 600 V | DC | |
 Molex | Header | Copper Alloy | -40 °C | 105 °C | Locking Ramp | 15 µin | Square | Solder | 8 | Glass Filled Liquid Crystal Polymer (LCP) | Through Hole | Board Guide | Gold | 0 A | Varies by Wire Gauge | Board Cable/Wire | 0.118 in | UL94 V-0 | 0.125 in | Male Pin | 0.39 in | All | Shrouded - 4 Wall | Yellow | Tin | 0.118 in | 2 | 600 V | DC |
