VCNL4020 Series
Manufacturer: Vishay Semiconductor Opto Division
Beta
⌘K
SENSOR OPT 540NM AMBIENT 10 VDFN
| Part | Mounting Type | Proximity Detection | Wavelength | Type | Termination Style | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Package / Case | Sensor Type | Sensing Distance Minimum | Sensing Distance Maximum | Output Type | Operating Temperature (Min) | Operating Temperature (Max) | Supplied Contents | Interface | Contents | Utilized IC / Part | Package Name |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Semiconductor Opto Division | Surface Mount | Yes | 540 nm | Ambient | SMD | 2.5 V | 3.6 V | 10-VDFN | Ambient Light IR | 0.039 " | 7.874 " | I2C | -40 °C | 105 °C | |||||
 Vishay Semiconductor Opto Division | 2.5 V | 3.6 V | Biosensor Light | Board(s) | I2C | Board | VCNL4020C | ||||||||||||
 Vishay Semiconductor Opto Division | Surface Mount | No | 550 nm | 2.5 V | 3.6 V | 10-SMD Module | I2C | -25 °C | 85 °C | 10-SMD | |||||||||
 Vishay Semiconductor Opto Division | Surface Mount | Yes | Ambient | 2.5 V | 3.6 V | 10-SMD No Lead | I2C | -25 °C | 85 °C | 10-SMD | |||||||||
Vishay Semiconductor Opto Division | Surface Mount | Yes | Ambient | SMD | 2.5 V | 3.6 V | 10-VDFN | Ambient Light IR | 0.039 " | 7.874 " | I2C | -25 °C | 85 °C | SMD | |||||
 Vishay Semiconductor Opto Division | 2.5 V | 3.6 V | Biosensor Light | Board(s) | I2C | Board | VCNL4020 |
