MMDP-009 Series
Manufacturer: Omnetics
Beta
⌘K
CABLE ASSY MICRO-D 9POS 1.5'
| Part | Number of Positions | 1st Connector | Contact Finish Thickness | Shielding | Contact Finish | Color | Length | Type | 2nd Connector | Shell Material | Finish | Connector Type | Termination | Number of Rows | Mounting Type | Contact Type | Current Rating (Per Contact) | Connector Style | Primary Material | Connector Layout Pitch | Connector Layout Row to Row | Flange Feature | Operating Temperature (Max) | Operating Temperature (Min) | Dielectric Material | Contact Form | Contact Material | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omnetics | 9 | Male Pins Plug | 50 µin | Unshielded | Gold | Individual Multiple | 1.5 ft | D-Type Micro-D | Individual Wire Leads | |||||||||||||||||||
 Omnetics | 9 | 50 µin | Gold | Aluminum | Electroless Nickel Nickel Plated | Male Pins Plug | Solder Cup | 2 | Free Hanging (In-Line) | Signal | 3 A | D-Type Micro-D | Metal | 0.05 | 0.05 | Housing Shell (Unthreaded) | 125 °C | -55 °C | Thermoplastic | Stamped | Copper Alloy | Aluminum Electroless Nickel Plated |
