ConnTAK50 Header, Dual Row, Right-Angle, Surface Mount, 22 Circuits / 20 Circuit Usable, Key B, Natural
ConnTAK50 Header, Dual Row, Right-Angle, Surface Mount, 22 Circuits / 20 Circuit Usable, Key B, Natural
ConnTAK50 Header, Dual Row, Right-Angle, Surface Mount, 22 Circuits / 20 Circuit Usable, Key B, Natural
| Part | Insulation Height | Pitch - Mating | Material Flammability Rating | Termination | Operating Temperature (Min) | Operating Temperature (Max) | Contact Material | Connector Type | Contact Finish - Mating | Shrouding | Contact Finish - Post | Contact Shape | Contact Finish Thickness - Mating | Insulation Material | Contact Type | Features | Fastening Type | Voltage Rating | Voltage Rating (Type) | Insulation Color | Number of Rows | Style | Row Spacing - Mating | Number of Positions | Number of Positions Loaded | Mounting Type | Number of Positions Loaded | Current Rating | Contact Length - Mating | Contact Finish Thickness - Post | Current Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Tin | Square | 39.4 µin | Glass Filled Nylon 9T Polyamide (PA9T) | Male Pin | Solder Retention | Latch Holder | 14 VDC | DC | Blue | 2 | Board Cable/Wire | 0.059 in | 22 | All | Right Angle Surface Mount | |||||
 Molex | |||||||||||||||||||||||||||||||
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Tin | Square | 39.4 µin | Glass Filled Nylon 9T Polyamide (PA9T) | Male Pin | Solder Retention | Latch Holder | 14 VDC | DC | Black | 2 | Board Cable/Wire | 0.059 in | 22 | Right Angle Surface Mount | 22 | |||||
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Tin | Square | 39.4 µin | Syndiotactic Polystyrene (SPS) | Male Pin | Push-Pull | 14 VDC | DC | Black | 2 | Board Cable/Wire | 0.059 in | 8 | All | Right Angle Surface Mount | 3 A | 0.256 in | 39.4 µin | |||
 Molex | 0.431 in | 0.071 in | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Square | 39.4 µin | Glass Filled Syndiotactic Polystyrene (SPS) | Male Pin | Latch Holder | 14 VDC | DC | Black | 2 | Board Cable/Wire | 0.059 in | 10 | All | Right Angle Surface Mount | 0 A | Varies by Wire Gauge | ||||||
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Tin | Square | 39.4 µin | Glass Filled Nylon 9T Polyamide (PA9T) | Male Pin | Solder Retention | Latch Holder | 14 VDC | DC | Violet | 2 | Board Cable/Wire | 0.059 in | 22 | All | Right Angle Surface Mount | |||||
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Tin | Square | 39.4 µin | Glass Filled Nylon 9T Polyamide (PA9T) | Male Pin | Solder Retention | Latch Holder | 14 VDC | DC | Natural | 2 | Board Cable/Wire | 0.059 in | 22 | All | Right Angle Surface Mount | |||||
 Molex | 0.413 in | 0.071 in | UL94 V-0 | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Square | 39.4 µin | Glass Filled Nylon 9T Polyamide (PA9T) | Male Pin | Push-Pull | 14 VDC | DC | Black | 2 | Board Cable/Wire | 0.059 in | 22 | Right Angle Surface Mount | 20 | 3 A | 0.327 in | |||||
 Molex | 0.431 in | 0.071 in | Solder | -40 °C | 105 °C | Brass | Header | Tin | Shrouded - 4 Wall | Square | 39.4 µin | Glass Filled Syndiotactic Polystyrene (SPS) | Male Pin | Latch Holder | 14 VDC | DC | Natural | 2 | Board Cable/Wire | 0.059 in | 8 | All | Right Angle Surface Mount | 0 A | Varies by Wire Gauge | ||||||
