ISL8010 Series

Catalog

MONOLITHIC 600MA STEP-DOWN REGULATOR WITH LOW QUIESCENT CURRENT

Part	Package Name	Voltage - Input (Max)	Output Configuration	Topology	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Output (Max)	Current - Output	Voltage - Output (Min/Fixed)	Voltage - Input (Min)	Synchronous Rectifier	Function	Mounting Type	Output Type	Number of Outputs	Package Length	Package Width	Frequency - Switching	Total Output Count	Non-Isolated Output Count	Board Type	Supplied Contents	Regulator Topology	Voltage - Output (Min)	Utilized IC / Part	Contents	Main Purpose	Voltage - Input (Minimum)	Voltage - Input (Maximum)
Renesas Electronics Corporation ISL8010IUZ	10-MSOP 10-TFSOP	5.5 V	Positive	Buck	85 °C	-40 °C	5.5 V	600 mA	0.8 V	2.5 V	Yes	Step-Down	Surface Mount	Adjustable	1	0.118 in	3 mm	1.4 MHz
Renesas Electronics Corporation ISL8010EVAL1							5.5 V	600 mA						Non-Isolated					1	1 count	Fully Populated	Board(s)	Buck	0.8 V	ISL8010	Board	DC/DC Step Down	2.5 V	5.5 V
Renesas Electronics Corporation ISL8010IUZ-T7	10-MSOP 10-TFSOP	5.5 V	Positive	Buck	85 °C	-40 °C	5.5 V	600 mA	0.8 V	2.5 V	Yes	Step-Down	Surface Mount	Adjustable	1	0.118 in	3 mm	1.4 MHz
