Newer Device Available PIC16F15313
Newer Device Available PIC16F15313
| Part | Core Size (Bit Width) | Program Memory Size | Program Memory Width | Program Memory Depth | Program Memory Type | Peripherals | Voltage - Supply (Vcc/Vdd) Maximum | Voltage - Supply (Vcc/Vdd) Minimum | Package Name | Mounting Type | Operating Temperature (Max) | Operating Temperature (Min) | Speed | RAM Size Width | RAM Size Depth | Core Processor | Package Length | Package Width | Number of I/O | Oscillator Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-SOIC | Surface Mount | 125 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.154 in | 3.9 mm | 5 | Internal | |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-DFN | Surface Mount | 85 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 2 mm | 3 mm | 5 | Internal | 8-VFDFN Exposed Pad |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-SOIC | Surface Mount | 85 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.154 in | 3.9 mm | 5 | Internal | |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-DIP 8-PDIP | Through Hole | 85 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.3 in | 7.62 mm | 5 | Internal | |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-MSOP 8-TSSOP 8-MSOP | Surface Mount | 125 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.118 in | 3 mm | 5 | Internal | |
Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-SOIC | Surface Mount | 85 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.154 in | 3.9 mm | 5 | Internal | |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-DFN | Surface Mount | 85 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 2 mm | 3 mm | 5 | Internal | 8-VFDFN Exposed Pad |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-DFN | Surface Mount | 125 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 2 mm | 3 mm | 5 | Internal | 8-VFDFN Exposed Pad |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-DIP 8-PDIP | Through Hole | 125 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.3 in | 7.62 mm | 5 | Internal | |
 Microchip Technology | 8 Bit | 1.5 KB | 12 | 1 K | FLASH | POR WDT | 5.5 V | 2 V | 8-SOIC | Surface Mount | 125 °C | -40 °C | 4 MHz | 8 bit | 41 | PIC | 0.154 in | 3.9 mm | 5 | Internal |
