1969598 Series

Catalog

HEADERS & WIRE HOUSINGS 10P FH PLUG VAL-U-LOK V2

Part	Note	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Contact Termination	Contact Type	Insulation Material	Row Spacing	Number of Rows	Number of Positions	Fastening Type	Connector Type	Pitch	Color
TE Connectivity AMP Connectors 1-1969598-0	Contacts Not Included	Free Hanging (In-Line)	-40 °C	105 °C	Crimp	Male Pin	Nylon 6/6 Polyamide (PA66)	0.165 in	2	10	Locking Ramp	Plug	0.165 in	Natural
TE Connectivity AMP Connectors 2-1969598-4	Contacts Not Included	Free Hanging (In-Line)	-40 °C	105 °C	Crimp	Male Pin	Nylon 6/6 Polyamide (PA66)	0.165 in	2	24 pos	Locking Ramp	Plug	0.165 in	Natural
TE Connectivity AMP Connectors 1969598-8	Contacts Not Included	Free Hanging (In-Line)	-40 °C	105 °C	Crimp	Male Pin	Nylon 6/6 Polyamide (PA66)	0.165 in	2	8	Locking Ramp	Plug	0.165 in	Natural
TE Connectivity AMP Connectors 1969598-4	Contacts Not Included	Free Hanging (In-Line)	-40 °C	105 °C	Crimp	Male Pin	Nylon 6/6 Polyamide (PA66)	0.165 in	2	4	Locking Ramp	Plug	0.165 in	Natural
TE Connectivity AMP Connectors 1-1969598-2	Contacts Not Included	Free Hanging (In-Line)	-40 °C	105 °C	Crimp	Male Pin	Nylon 6/6 Polyamide (PA66)	0.165 in	2	12	Locking Ramp	Plug	0.165 in	Natural
