EL5163 Series

Catalog

500MHZ LOW POWER CURRENT FEEDBACK AMPLIFIERS WITH ENABLE

Part	Voltage - Input Offset	Voltage - Supply Span (Min)	-3db Bandwidth	Amplifier Type	Current - Input Bias	Slew Rate	Mounting Type	Number of Circuits	Current - Supply	Voltage - Supply Span (Max)	Package Name	Operating Temperature (Min)	Operating Temperature (Max)	Current - Output / Channel	Package / Case
Renesas Electronics Corporation EL5163IWZ-T7	1.5 mV	5 V	500 MHz	Current Feedback	2 µA	4000 V/µs	Surface Mount	1	1.5 mA	12 V	SOT-23-5	-40 °C	85 °C
Renesas Electronics Corporation EL5163IW-T7A	1.5 mV	5 V	500 MHz	Current Feedback	2 µA	4000 V/µs	Surface Mount	1	1.5 mA	12 V	SOT-23-5	-40 °C	85 °C	100 mA
Renesas Electronics Corporation EL5163ICZ-T7A	1.5 mV	5 V	500 MHz	Current Feedback	2 µA	4000 V/µs	Surface Mount	1	1.5 mA	12 V	SC-70-5	-40 °C	85 °C		5-TSSOP SC-70-5 SOT-353
Renesas Electronics Corporation EL5163ICZ-T7	1.5 mV	5 V	500 MHz	Current Feedback	2 µA	4000 V/µs	Surface Mount	1	1.5 mA	12 V	SC-70-5	-40 °C	85 °C	100 mA	5-TSSOP SC-70-5 SOT-353
