MIC29372 Series

Catalog

IC REG LIN POS ADJ 750MA TO263-5

Part	Output Type	Voltage - Output (Max)	Control Features	Current - Output	Number of Regulators	Operating Temperature (Max)	Operating Temperature (Min)	Protection Features	Package Name	Package Leads	Voltage Dropout (Max)	Voltage - Output (Min/Fixed)	Current - Supply (Max)	Mounting Type	Output Configuration	Voltage - Input (Max)	Current - Quiescent (Iq)	Package / Case
Microchip Technology MIC29372BU	Adjustable	26 V	Enable	750 mA	1	125 °C	-40 °C	Over Current Over Temperature	D2PAK TO-263-5	5 Leads	0.75 V	1.24 V	16 mA	Surface Mount	Positive	26 V	300 µA
Microchip Technology MIC29372WU	Adjustable	26 V	Enable	750 mA	1	125 °C	-40 °C	Over Current Over Temperature	D2PAK TO-263-5	5 Leads	0.75 V	1.24 V	16 mA	Surface Mount	Positive	26 V	300 µA
Microchip Technology MIC29372BT	Adjustable	26 V	Enable	750 mA	1	125 °C	-40 °C	Over Current Over Temperature	TO-220-5		0.75 V	1.24 V	16 mA	Through Hole	Positive	26 V	300 µA	TO-220-5
Microchip Technology MIC29372WT	Adjustable	26 V	Enable	750 mA	1	125 °C	-40 °C	Over Current Over Temperature	TO-220-5		0.75 V	1.24 V	16 mA	Through Hole	Positive	26 V	300 µA	TO-220-5
Microchip Technology MIC29372WU-TR	Adjustable	26 V	Enable	750 mA	1	125 °C	-40 °C	Over Current Over Temperature	D2PAK TO-263-5	5 Leads	0.75 V	1.24 V	16 mA	Surface Mount	Positive	26 V	300 µA
