282838 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

TERM BLK 3P SIDE ENTRY 10MM PCB

Part	Color	Mating Orientation	Positions Per Level	Pitch	Wire Termination	Features	Current	Mounting Type	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Voltage	Number of Levels	Housing Material	Screw Material	Screw Plating	Contact Material	Plating	Clamp Material	Clamp Plating	Torque - Screw	Screw Thread
TE Connectivity AMP Connectors 282838-3	Green	Horizontal with Board	3	0.394 in	Rising Cage Clamp Screw	Interlocking (Side)	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
TE Connectivity AMP Connectors 282838-7	Green	Horizontal with Board	3	0.394 in	Rising Cage Clamp Screw	Interlocking (Side) Positions Stamped	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
TE Connectivity AMP Connectors 1-282838-0	Green	Horizontal with Board	9	0.394 in	Rising Cage Clamp Screw	Interlocking (Side)	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
TE Connectivity AMP Connectors 282838-9	Green	Horizontal with Board	8	0.394 in	Rising Cage Clamp Screw	Interlocking (Side)	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
TE Connectivity AMP Connectors 282838-5	Green	Horizontal with Board	5	0.394 in	Rising Cage Clamp Screw	Interlocking (Side)	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
TE Connectivity AMP Connectors 282838-4	Green	Horizontal with Board	4	0.394 in	Rising Cage Clamp Screw	Interlocking (Side)	13.5 A	Through Hole	16 AWG	30 AWG	600 V	1	Nylon 6/6 PA66 Polyamide	Brass	Nickel Plated	Brass	Tin Plated	Brass	Nickel Plated	0.68 Nm	M3
